From Titanium to Mirror Finish.
From roughing aluminum to finishing jewelry wax, K1's 1500W spindle doesn't slow down — and neither do you.
![The Pro-Grade [br-pc]Desktop 5-Axis CNC](http://infimaker.com/cdn/shop/files/20260518190500_296_2292_webp_b56f18c8-c5e6-4d9b-a934-91e4aea40b5f.webp?v=1779442436&width=1200)
COMING SOON ON
The Pro-Grade Desktop 5-Axis CNC
Simplified CAM workflow powered by AI
Pay $50 Deposit Now for $200 Extra Off — VIP ONLY Special Starts at $4,999
Claim Your Offer Now
Secure your $3600 in savings now before this deal is gone forever.
Everything You Need to Create
Multi-tool ATC System
6-Slot ATC with Integrated Probe
5-Axis Simultaneous
All Axes Move as One
0.01mm Industrial Precision
Al-Assisted Creation
Text/Image → 3D + CAM Workflow
One-Tap Auto Calibration
Smart Camera Setup
Multi-Material Capabilities
True 5-axis simultaneous motion
Create geometries once impossible in a single setup.
AI Creation Engine
From text or image to finished part — no CAD needed.
Fully automated workflow
Load the material, press start, walk away.
0.01mm precision
The same tolerance as industrial-grade machines, in a desktop footprint.
This isInfiMaker K1.
Full 5-Axis. All Moving as One.
5-Axis Simultaneous
All 5 axes move simultaneously, maintaining optimal tool orientation across every surface: freeform, undercut, and compound, all in a single setup.
1500W. 20,000 RPM. 0.01mm.
0.01mm Positioning Accuracy ｜ Redefined with 2× Precision
Fine enough to carve a hairline groove into titanium. Smooth enough that your jewelry pieces come off the machine ready to polish, not ready to file.
1500W · 20,000 RPM
120 × 120 × 120mm 5-Axis Travel
Space that never holds you back.
Nearly 2× the working volume of comparable desktop machines. Big enough for a functional part, precise enough for fine jewelry.
Idea to G-Code. No CAD Degree Required.
No manual programming required. Advanced AI generates the optimal toolpaths automatically, turning your ideas into physical creations with just one click.
Key Features
AIGC Modeling
Words/photos → 3D models
Describe what you want or drop in a reference image. K1 generates the geometry, checks it for machinability, and prepares the cut file. The whole thing happens on-device in under 2 minutes.
Cloud CAM
Multi-Device Control
K1 keeps you connected to every cut, every move, and every idea in progress.
AI Vision
Smart Material Detection
The built-in camera scans your stock and automatically sets feeds, speeds, and cut depth — no manual input, no setup time.
Visual UI
Direct Control Display
A purpose-built interface designed for the way you work. Every control where you expect it. Every status visible at a glance.
LOAD STOCK. PRESS START. DONE.
Set It Up. Let K1 Take Over. From stock detection to tool changes, K1 automates the workflow so you can focus on what comes next.
6-Slot ATC with Integrated Probe
Titanium to Wax.
One Machine.
Aluminum
Timing Pulley
Titanium
Fidget Spinner
Brass
Statue of Liberty
Hardwood
Eagle Sculpture
Epoxy Tooling
Yacht Model
Jewelry Wax
Wax Ring
EVERY JOB. FULLY CAPTURED. AI CUTS THE HIGHLIGHTS.
From raw material to final cut, every step is recorded. K1 automatically creates a highlight reel when the job is complete. Share your build in one tap.
INDUSTRIAL SPEC. WORKSHOP QUIET. HOME READY.
<70dB 2 · Enclosed Dust Control Quieter machining and a cleaner enclosed workflow for everyday creation.
The light strip changes color with every machine state. Cutting, standby, alert — no screen needed.
COMING SOON ON
Pay $50 Deposit Now for $200 Extra Off
- VIP ONLY Special Starts at $4,999
Specifications
Hardware Parameters
Smart Numerical Control System
Motinfi™ System
X/Y/Z Axis Travel
220 x 160 x 180 mm
B-Axis Travel
-30-110 °
C-Axis Travel
360°
X/Y/Z Axis Repeatability
0.01 mm
B/C Axis Repeatability
40"
X/Y/Z Axis Max. Rapid Rate
4500 mm/min
X/Y/Z Axis Max. Cutting Feed Rate
2500 mm/min
B/C Axis Max. Rotation Rate
B: 15 RPM (r/min)
C: 30 RPM (r/min)
Spindle Power (Max)
1.5 KW
Spindle Speed
20000 RPM (r/min)
Tool Changer Capacity
6-tools automatic (ATC)
Worktable Load
15 kg
Max. Workpiece Size
5-axis Max.1
Workpiece Size: 120x120x120mm
3-axis
Workpiece Size: 220x150x150mm
3+2 axis
Workpiece Size: 170x150x150mm
(*In specific machining modes.Varies by mode and fixturin）
Smart HD Camera
Depth Camera
System Features
Noise
< 70dB
2RTCP (Rotational Tool Center Point)
Support
Automatic Workpiece Centering (Auto Edge Finder)
Support
Breakpoint Resume Machining
Support
MQL (Minimum Quantity Lubrication)
Support (Optional)
Software Features
AIGC Image & Text Generation Model
Support
Time-Lapse Video
Support
Material Recognition
Support
Video/Camera Monitoring (included online stream)
Support
Multi-Platforms Software
InfiStudio （Windows/macOS/Android/iOS）
Others
Materials
Titanium, Steel, Aluminum, Brass, Copper, Wood, Acrylic, Wax, Jade, Resin, Engineering Plastics & Composites. 100+ machining applications
Input Voltage
110-240V AC
Rated Power
2.2KW
Dimensions
Machine Weight
Around 110kg/243lb
Machine Dimensions
560x690x800mm / 28.74x21.65x23.62inches
¹ For the maximum 5-axis workpiece size: the workpiece must be centered relative to the fixture and mounted flush against the fixture base.
² This noise level was measured under the following machining conditions: Machining stainless steel with the following toolpath parameters: 10,000 RPM, 2,000 feed rate, 0.1 mm depth of cut, and 4 mm row spacing; a D4 round-nose end mill was used; measurements were taken in an open space 1 meter away from the machine. Noise levels may vary significantly depending on the parameters used or when machining different materials with the same parameters.
ABOUT INFIMAKER
FAQs
What is Kickstarter?
Kickstarter is the world's largest crowdfunding platform for creative projects. Over 10 million people have backed projects on Kickstarter, getting innovative products at significant discounts. You won't be charged until the campaign successfully concludes.
When will Deposits and Discounts be refunded?
$50 Deposit VIPs unlock the exclusive VIP price of $4,999 on InfiMaker K1 during our time-limited pre-launch offer.
Non-Deposit users will have a launch price of $5,199 on InfiMaker K1.
What if I change my mind after placing the deposit?
service@infimaker.com from the address used to place your deposit, and we'll process your full refund within 7 business days.
Why do I need to use the same email for the deposit and Kickstarter order?
We match your Kickstarter email against your deposit email to confirm eligibility and process your refund and bonus correctly. Using the same email ensures nothing gets missed.
When will the InfiMaker K1 be launched on Kickstarter?
InfiMaker K1 is scheduled to launch on Kickstarter in July 2026.
Is the $50 deposit really refundable?
Yes — 100%.
If you decide not to back InfiMaker K1 on Kickstarter, your full deposit is returned. If you do back it, your deposit works harder: you'll receive an additional $200 off, effectively getting $250 back ($50 deposit + $200 discount) and securing the lowest VIP price guaranteed.
